Fixing Sprig Templating Issues In Argo Workflows

by Alex Johnson 49 views

If you're encountering problems with Sprig templating within Argo Workflows, you're not alone. This article dives into a specific issue reported between Argo Workflows versions 3.6.5 and 3.6.12, where Sprig templating stopped being correctly interpreted. We'll explore the problem, provide a reproducible example, and discuss potential solutions.

Understanding the Issue: Sprig Templating Not Respected

In Argo Workflows, Sprig templating is a powerful feature that allows you to dynamically generate workflow configurations using a rich set of template functions. These functions can manipulate strings, perform mathematical operations, work with dates, and much more. However, a regression appears to have been introduced between versions 3.6.5 and 3.6.12, causing Sprig template expressions to be rendered as plain text instead of being evaluated.

This issue can manifest in various ways, such as environment variables not being set correctly, conditional logic not working as expected, or workflow names not being generated dynamically. When Sprig templating fails, it can lead to unexpected workflow behavior and errors. Diagnosing such issues is crucial to maintain the reliability and automation capabilities of your workflows.

Demonstrating the Problem with a Minimal Workflow

To illustrate the issue, consider the following minimal workflow definition. This workflow attempts to use Sprig's dig function to extract values from workflow labels, providing a default value if the labels are not set. Specifically, the workflow checks for the cat.splunk8s.io/workflow-template and workflows.argoproj.io/workflow-template labels within the workflow's labels and defaults to 'undefined' if neither is found. Here’s the YAML definition:

metadata:
 name: regression-test
spec:
 entrypoint: argosay
 templates:
 - name: argosay
 script:
 env:
 - name: RUNBOOK
 value: "{{=sprig.dig('cat', 'splunk8s', 'io/workflow-template', nil, workflow.labels) ?? sprig.dig('workflows', 'argoproj', 'io/workflow-template', 'undefined', workflow.labels)}}"
 image: alpine:latest
 command:
 - '/bin/sh'
 source: |
 #!/usr/bin/env bash
 set -eo pipefail

 echo "$RUNBOOK"

In Argo Workflows version 3.6.5, this workflow correctly evaluates the Sprig expression. The expected output varies depending on the labels set: it prints undefined if neither cat.splunk8s.io/creator-email nor workflows.argoproj.io/creatore-email are set, dmarquez.at.splunk.com when submitted through the UI, and the value of cat.splunk8s.io/creator-email when created through internal automation. The ability to adapt the workflow output based on its execution context using Sprig templating is essential for dynamic configuration.

However, in version 3.6.12 and later, the workflow prints the raw Sprig expression:

{{=sprig.dig('cat', 'splunk8s', 'io/workflow-template', nil, workflow.labels) ?? sprig.dig('workflows', 'argoproj', 'io/workflow-template', 'undefined', workflow.labels)}}

This behavior clearly indicates that the Sprig templating is not being processed, highlighting the regression issue.

Analyzing Logs from the Workflow Controller

To further understand the problem, analyzing the logs from the Argo Workflow Controller can provide valuable insights. Let's compare the logs from versions 3.6.5 and 3.6.12.

Argo Workflows 3.6.5 Logs

The logs from version 3.6.5 show the controller correctly processing the workflow and resolving the template. Here’s a snippet of the relevant logs:

time="2025-12-02T14:24:17.419Z" level=info msg="Processing workflow" Phase= ResourceVersion=1845256500 namespace=stack-orchestration workflow=regression-test-2
time="2025-12-02T14:24:17.420Z" level=debug msg="Resolving the template" base="*v1alpha1.Workflow (namespace=stack-orchestration,name=regression-test-2)" tmpl="*v1alpha1.WorkflowStep (argosay)"
...
time="2025-12-02T14:24:17.426Z" level=debug msg="Evaluating node regression-test-2: template: *v1alpha1.WorkflowStep (argosay), boundaryID: " namespace=stack-orchestration workflow=regression-test-2
...

These logs indicate that the controller is actively resolving and evaluating the template, which includes the Sprig expression. The Evaluating node message is a key indicator that the template processing is occurring as expected.

Argo Workflows 3.6.12 Logs

In contrast, the logs from version 3.6.12 do not show the same template evaluation behavior. Here’s a snippet from the 3.6.12 logs:

time="2025-12-02T14:28:36.771Z" level=info msg="Processing workflow" Phase= ResourceVersion=2089960120 namespace=stack-orchestration workflow=regression-test-24xsq
...

The absence of log messages related to template resolution and evaluation suggests that the Sprig expression is not being processed at all. This confirms that the regression issue is preventing the template engine from interpreting the expression, leading to the raw expression being printed instead of the evaluated result. Properly functioning Sprig templating relies on these log messages to ensure configurations are correctly processed.

Identifying the Root Cause and Potential Solutions

Given the observed behavior and log analysis, it’s clear that a regression in the template processing engine was introduced between Argo Workflows versions 3.6.5 and 3.6.12. Identifying the exact commit or change that caused this regression would require a deeper dive into the Argo Workflows codebase and release notes for these versions. However, we can focus on potential solutions and workarounds.

Potential Solutions

  1. Downgrade to a Stable Version: If you require Sprig templating and are experiencing this issue, downgrading to version 3.6.5 is a viable workaround. This ensures that the templating engine functions as expected.
  2. Upgrade to the Latest Version: Check if the issue has been resolved in a more recent version of Argo Workflows. Upgrading to the latest stable release might include bug fixes that address this regression.
  3. Investigate Configuration: While the issue appears to be a regression, it's worth double-checking your workflow and Argo Workflows configuration. Ensure that there are no misconfigurations that might be interfering with the template processing.
  4. File a Bug Report: If the issue persists in the latest versions, consider filing a detailed bug report with the Argo Workflows project. Provide the minimal workflow example and log snippets to help the developers diagnose and fix the issue.

Community Support and Bug Reporting

The Argo Workflows community is active and responsive. Engaging with the community through forums, Slack channels, or GitHub issues can provide additional insights and support. When reporting a bug, be as specific as possible, including:

  • Argo Workflows version
  • Kubernetes version
  • Minimal workflow example
  • Relevant logs from the workflow controller
  • Steps to reproduce the issue

Conclusion: Restoring Sprig Templating Functionality

Sprig templating is a crucial feature in Argo Workflows, enabling dynamic and flexible workflow configurations. The regression issue between versions 3.6.5 and 3.6.12 highlights the importance of thorough testing and version management. By understanding the problem, analyzing logs, and applying potential solutions, you can restore Sprig templating functionality and ensure your workflows operate as expected.

By staying informed and proactive, you can continue to leverage the power of Argo Workflows for your automation needs. For further reading and community support, visit the Argo Workflows Documentation.
